ZW-ODF-ZZW3

Wholesale and Partners Only

Vehicle Dimensions 265 × 88 × 102 cm
Motor Specifications Differential 35 high 1000W motor
Maximum Speed 45 km/h
Battery Configuration No battery (bare vehicle price, range depends on selected battery capacity)
Controller 15-tube double-row controller
INQUIRY NOW

CRAFTSMANSHIP 01

INTEGRATED HEAVY-DUTY PROPULSION SYSTEM

A flagship industrial platform engineered with a high-fidelity 1000W differential motor. Redefining heavy transport through a meticulous balance of 800kg load capacity and 45km/h operational agility.

CRAFTSMANSHIP 02

REINFORCED STRUCTURAL ARCHITECTURE

A robust high-carbon steel chassis depth-coupled with a leaf spring suspension matrix. Engineered for maximum structural integrity and 800kg load redundancy across diverse and challenging terrains.

CRAFTSMANSHIP 03

PRECISION INTERFACE & MECHANICAL MASTERY

Integrating high-output LED optics with a digital telemetry dashboard. Featuring high-response hydraulic damping and dual disc braking technology for absolute command under the most rigorous industrial cycles.
Configuration
Parameters Details
Vehicle Dimensions 265 × 88 × 102 cm
Motor Specifications Differential 35 high 1000W motor
Maximum Speed 45 km/h
Battery Configuration No battery (bare vehicle price, range depends on selected battery capacity)
Controller 15-tube double-row controller
Tire Specifications Front / Rear 3.00-10
Frame Material High Carbon Steel
Lighting System LED Headlight
Front Shock Absorption Hydraulic Damping Shock Absorber
Rear Shock Absorption Leaf spring shock absorption
Braking System Front and Rear Dual Disc Brakes
Handlebar Functions Three-speed Adjustment, Reverse Function
Seat Cushion Configuration High-elasticity Comfort Cold-foam Seat Cushion
Carriage dimensions 108 × 80 cm
Maximum load 800 kg
