| Parameters |
Details |
| Model |
6-EVF-60 |
| Nominal Voltage |
12V |
| 10-hour rate capacity (67Ah @ 10hr to 1.75V/cell) |
67 Ah |
| Length |
261 mm |
| Width |
165 mm |
| Height |
169 mm |
| Total Height |
169 mm |
| Reference Weight |
Approx. 20.0 kg |
| Terminal |
I7 (M6 X 16) |
| Container Material |
ABS UL94-HB (Optional FR ABS UL94-V0) |
| Cycle Life @ 100% DOD |
400 ~ 600 times |
| Limited Current |
≤ 0.18C₁₀A |
| Limited Voltage @ 25°C |
14.7V – 14.8V |
| Floating Voltage @ 25°C |
14.0V – 14.1V |
| Charging Operating Temperature Range |
0℃ ~ 40℃ |
| Discharging Operating Temperature Range |
-15℃ ~ 50℃ |
| Storage Operating Temperature Range |
-15℃ ~ 40℃ |
| Optimum Operating Temperature |
25℃ ± 2℃ |
| Core Technology (Energy Density) |
Energy Density Improved by 110% |
| Core Technology (Grid Corrosion) |
Rare Earth Alloy Grid Corrosion Resistance Improved by 50% |
| Core Technology (Acid Stratification) |
Nano-silica Gel Technology 0% Acid Stratification |
